Intermittent letter press high-speed label presses

Option device: 1.second pass system 2.flexo UV coating equipment 3.Rotary die cutter device Characteristics : 1. Adopt paper reciprocating mode. One printing roller could do the job regardless the repeat size. 2. Adopt servo control system to control every roll in printing system, which make the optimized performance of machine . 3. Optimization of ink rollers could prevent bar marking and ghosting to improve the printing quality. 4. The supply of ink will change proportionally with the speed of the machine to make printing result better. 5. Malfunction of the machine would be shown on the screen automatically, which will shorten the repair time. 6. Paper unwinding, printing, UV vanish, rotary diecutting, waste removal and rewinding can be completed in one pass. 7. This equipment is suitable for printing middle & upper class labels in large ,middle and small batch of production. Technical specification : Max. Web width310mmMax. printing width290mmPrinting repeat50-260mmColor2-8 colorThickness of substrate0.1 0.3mmMachine speed30-250r/minMax. unwind diameter700mmMax. Rewind diameter700mmTotal capacity17.3KW Not Including UVPower380V/AC. Three-phase 50/60H 50A 17.3KVAOverall dimension(L×W×H)6800×1600×1400mmMachine weight6000kg/6 colorsNotes: With the viriation of the length to be printed, machine speed should be changed. *Its overall dimension and manufacturing Process are subject to change without further notice.
