Rotary&intermittent letter press label machine

Characteristics : 1. Servo-control System Achieves Optimization Control Of Machine, Which Assure High Accuracy And Stability For Registration. 2.Creative Front & Back Vacuum Driving Roller And Ceramic Roller In Paper-feeding System Saves Extra Substrate For Removing Rider Wheels. 3.Special Printing Unit Combined Rotary Letter Press & Intermittent Printing, Convert Both Functions Easily On One Machine. 4.Creative Lateral & Lineal Registration System Electrical Controlled Can Be Adjusted Easily Through The Panel On Printing Unit Or Center Control Screen. 5.Creative Ink Distributing System Avoids Bar Marking And Ghosting, Inks Volume Varies With Printing Speed Automatically. 6.This Machine Is Best One To Print Middle & Top Class Labels In Large, Medium And Small Batch Of Production. 7.Indicate Malfunction Of Machine On The Center Control Screen To Speed Up The Maintenance Of Machine. Technical specification : Max. Web width310mmMax. printing width300mmPrinting repeatintermittent 50-260mm rotary 55 96T(174.6-304.8mm)Color2-9 colorsThickness of substrate0.1 0.3mmMachine speedintermittent 250r/min rotary 75m/minMax. unwind diameter700mmMax. Rewind diameter700mmTotal capacity17.3KW (Not Including UV)Power380V/AC. Three-phase 50/60H 50AOverall dimension(L×W×H)6800×1600×1400mmMachine weight6800kg/6 colorsNotes: With the viriation of the length to be printed, machine speed should be changed. *Its overall dimension and manufacturing Process are subject to change without further notice.
