ZTJ330 LABEL OFFSET PRINTING MACHINE

DETAILED PRODUCT DESCRIPTION: Characteristics : 1.Servo driven : Independent servo driven system in each unit to guarantee stable register at high printing speed. 2.Printing unit : Use the most advanced inking system which has 23 inking rolls, four large diameter form rolls included and alcohol damping system to guarantee printing quarlity. 3.Pre-register system : Based upon the printing length, log data into the sliding control station, each unit willautomatically be adjusted to its ready position. 4.Register system : Each printing unit can remote adjust register which includes lineal, lateral and skewingwithout stopping the press to save time and reduce the waste of substrate. 5.Vacuum backflow control unwind : Vac cum back flow cylinder should be able to prevent scratches on the back of P/S label during intermittent motion. 6.Joystickless : Fully automatic operation system including pressure adjustment, inking roll washup, roller impression, etc. 7.Easy to operate: Equipped with sliding touch screen control station which can be moving around to increasethe efficiency of operator. 8.Printing size : Paterted technology to minimize printing size to achieve larger scale of variable size printing. 9.Control system : Apply electronic component from famous international brand to guarantee long term reliable operation. 10.Lubrication system : Centralized automatic lubrication. Technical specification : Max. web width330mmMax. printing width320mmPrinting repeat100 320mmThickness of substrate0.1 0.3mmMachine speed30-200rpm(50M/min)Max. unwind diameter700mmMax. rewind diameter700mmPneumatic requirement7kg/cm2Total capacity30kw/6 colorswithout UV 30kw/6 colors (Not including UV)UV capacity4.8/kw/colors 4.8kw/colorPowerThree-phase 380v three phase 380VOverall dimension(L×W×H)9500×1700×1600mmMachine weightabout 9/t/6 colors about 9 ton/6 colorsNotes: With the viriation of the length to be printed, machine speed should be changed. *Its overall dimension and manufacturing Process are subject to change without further notice.
